5 Ton Girder Gantry Crane for Plastic Injection Mold Handling — Enhanced Product Description
Short Description
The 5 Ton Box Girder Gantry Crane is designed for plastic injection mold handling applications. Featuring a single girder box girder structure, it provides an efficient solution for lifting, transporting, and positioning injection molds within production workshops. The crane is designed to meet workshop height limitations while improving mold handling efficiency, positioning accuracy, and production workflow. Customized configurations are available according to workshop dimensions and mold handling requirements.
| Technical Specifications | |
| Parameter | Specification |
| Product Name | 5 Ton Box Girder Gantry Crane |
| Crane Type | Single Girder Box Girder Gantry Crane |
| Application | Plastic Injection Mold Handling |
| Rated Capacity | 5 t |
| Span | 12 m |
| Lifting Height | 3 m |
| Workshop Height Limit | 4.6 m |
| Hoisting Mechanism | Electric Hoist |
| Traveling Method | Rail Traveling |
| Girder Type | Box Girder |
| Control Method | Pendant / Remote Control (Optional) |
| Custom Design | Available |
Specifications are summarized from the reference project and may be customized according to application requirements.
| Design & Components | |
| Item | Description |
| Crane Structure | Single girder box girder gantry crane |
| Main Girder | Box girder design |
| Hoisting System | Electric hoist |
| Traveling Mechanism | Rail traveling wheels |
| Control System | Electrical control system |
| Safety Devices | Overload protection, emergency stop, limit switches |
| Customization | Adjustable lifting beam and application-specific attachments |
| Main Features | |
| Feature | Description |
| Lightweight Structure | Box girder design provides strength while reducing structural weight. |
| Space Optimization | Designed for workshops with limited overhead clearance. |
| Stable Operation | Box girder construction improves rigidity and stability during lifting. |
| Easy Installation | Modular structure simplifies installation and commissioning. |
| Easy Maintenance | Accessible components reduce maintenance requirements. |
| Custom Configuration | Can be configured according to mold handling requirements. |
Typical Applications
Plastic injection mold handling
Injection molding workshops
Mold loading and unloading
Plastic manufacturing plants
Machine loading operations
Material handling within production workshops
Frequently Asked Questions
What is the lifting capacity of this gantry crane?
The reference configuration is designed with a 5-ton lifting capacity for plastic injection mold handling applications.
Why is a box girder design used?
The box girder design provides rigidity and stability while maintaining a relatively lightweight crane structure for efficient mold handling.
Can the crane be customized?
Yes. The reference page states that the crane can be customized with adjustable lifting beams, specialized attachments, and different control options according to application requirements.
What industries is this crane suitable for?
It is designed for plastic injection mold handling, including injection molding workshops and plastic manufacturing facilities where molds need to be lifted, positioned, and transferred safely.
